Google OAuth2 C# 147

 in Authentication / C# / Google Drive API  tagged C# .net / Google Developers Console / Google Oauth2 / OAuth2 / Sample by

Google Drive API

Have you been trying to access Google Drive with C#? Do you need to upload files to Google Drive with .net? In this post, we will be looking into accessing Google Drive using OAuth2 with C# using the Google .net client library.   You can change the scope easily to connect to any of the other API’s I am just using drive as an example.   If you are interested in learning how OAuth2 works without using Google’s library’s I have a post that explains it all from the start. Google API and Oath2

Update: I have a new tutorial series that walks you through using the Google Drive API it starts with Google Drive API C#, I also have one for using Google Analytics it starts with Google Analytics API C# you will find them both more up to date then this tutorial.

Requirements

Create Google Apis app

  1. Create a app in Google Apis Console
  2. APIs & auth -> APIs -> Enable Drive API and Drive SDK.
  3. APIs & auth -> credentials.  Create a new Client Id -> installed Application type other.
  4. Take a note of your Client ID and Client secret
  5. APIs & auth -> consent screen Make sure to set an email address and a product name.

Visual studio project

Create project in Visual Studio, I recommend either a console application or a win forms application for testing.   Install the following NuGet package to your project.

pm> install-package google.apis.drive.v2

OAuth2

Oauth2RequestBrowser

In order to access most of Google’s APIs you need to be authenticated, we use OAuth to authentcate.     Open Authentication is a way for your users to allow your program to access there data for them.   One thing that I want to note is that you are giving OAuth2 access via your Google Account.   Your web browser needs to be logged into the Google Account that has access to the data you want to request.  (If you are releasing this application to the public its a good idea to put a note about this some place or you will get support calls.  Been there done that)

There are two ways of requesting user access with Open Authentication.   The first is to use something called FileDataStore this will store the RefreshToken on the PC in a file in the %AppData% directory.   The other way of doing it is to create your own implantation of iDataStore, this will enable you to save the RefreshToken to a database for example.

Code Using FileDatastore

 var credential = GoogleWebAuthorizationBroker.AuthorizeAsync(new ClientSecrets { ClientId = "YourClientId",
                                                                              ClientSecret = "YourClientSecret" },
                                                          new[] { DriveService.Scope.Drive,
                                                                  DriveService.Scope.DriveFile },
                                                          "user",
                                                          CancellationToken.None,
                                                          new FileDataStore("Drive.Auth.Store")).Result;

ClientId and Secret

The first thing we are doing is sending Google the information about our application.    Google likes to keep track of our applications so that they know who is accessing there API and how much they have accessed it. This information was found in the Google Developer console when you registered your application.

Scopes

All of the API’s have different scopes depending on what information you would like to access.  The user will be told what information you need and they can decided at that time if they want to let you have access to the information or not.   If they don’t then they can’t use your program.

Tip: Make sure that you only request the permissions you actually need.

Users are becoming more protective of there data, they may not grant you application access and you will loose users.   Google Drive Scope Reference

FileDataStore

new FileDataStore(“Drive.Auth.Store”)

Once the user gives you access the information is saved on there machine so you wont have to ask them again.   You can find it here:

%AppData%\Roaming\Drive.Auth.Store\Google.Apis.Auth.OAuth2.Responses.TokenResponse-user

The file format is Json so you can open it in a text editor if you want.

{"access_token":"",
"token_type":"Bearer",
"expires_in":3600,
"refresh_token":"",
"Issued":""
}

Expires in is used by the system to calculate when the the access token has expired.

That’s it really that’s all you need to know to get OAuth2 working with any of the Google API’s just change the scope you need depending on the API you are accessing.     In my next tutorial we will look more into the Google Drive API, check back for Google Analytic s API tutorials coming soon .

User

If I send  ”Linda” using FileDataStore and authorize the access the next time I load the application I don’t have to authorize it again because the file exists in my %appdata% with my stored refresh Token.  If I change that to say LindaLawton the next time I load it will ask me to authorize it again.   This is how you keep different users authentication organized by there login.   If you have more then one user using the same machine they will then each have there own information stored in %appData%.

In this picture we can see that we are now authenticated and can go on to creating a Google drive service for accessing Google drive data. Drive Access tutorial
RefreshToken

Stored refresh-Token

In order to load a stored refresh token someplace other then %appdata% you need to create your own implementation of IDataStore. I have a few examples for you in the GitHub project Google-Dotnet-Samples Authentication.

 ///
 /// Saved data store that implements .
 /// This Saved data store stores a StoredResponse object.
 ///
    class SavedDataStore : IDataStore
    {
        public StoredResponse _storedResponse { get; set; }
        ///
        /// Constructs Load previously saved StoredResponse.
        ///
        ///Stored response
        public SavedDataStore(StoredResponse pResponse)
        {
            this._storedResponse = pResponse;
        }
        public SavedDataStore()
        {
            this._storedResponse = new StoredResponse();
        }
        ///
        /// Stores the given value. into storedResponse
        /// .
        ///
        ///The type to store in the data store
        ///The key
        ///The value to store in the data store
        public Task StoreAsync(string key, T value)
        {
            var serialized = NewtonsoftJsonSerializer.Instance.Serialize(value);
            JObject jObject = JObject.Parse(serialized);
            // storing access token
            var test = jObject.SelectToken("access_token");
            if (test != null)
            {
                this._storedResponse.access_token = (string)test;
            }
            // storing token type
            test = jObject.SelectToken("token_type");
            if (test != null)
            {
                this._storedResponse.token_type = (string)test;
            }
            test = jObject.SelectToken("expires_in");
            if (test != null)
            {
                this._storedResponse.expires_in = (long?)test;
            }
            test = jObject.SelectToken("refresh_token");
            if (test != null)
            {
                this._storedResponse.refresh_token = (string)test;
            }
            test = jObject.SelectToken("Issued");
            if (test != null)
            {
                this._storedResponse.Issued = (string)test;
            }
            return TaskEx.Delay(0);
        }

        ///
        /// Deletes StoredResponse.
        ///
        ///The key to delete from the data store
        public Task DeleteAsync(string key)
        {
            this._storedResponse = new StoredResponse();
            return TaskEx.Delay(0);
        }

        ///
        /// Returns the stored value for_storedResponse
        ///The type to retrieve
        ///The key to retrieve from the data store
        /// The stored object
        public Task GetAsync(string key)
        {
            TaskCompletionSource tcs = new TaskCompletionSource();
            try
            {
                string JsonData = Newtonsoft.Json.JsonConvert.SerializeObject(this._storedResponse);
                tcs.SetResult(Google.Apis.Json.NewtonsoftJsonSerializer.Instance.Deserialize(JsonData));
            }
            catch (Exception ex)
            {
                tcs.SetException(ex);
            }
            return tcs.Task;
        }

        ///
        /// Clears all values in the data store.
        ///
        public Task ClearAsync()
        {
            this._storedResponse = new StoredResponse();
            return TaskEx.Delay(0);
        }

        ///// Creates a unique stored key based on the key and the class type.
        /////The object key
        /////The type to store or retrieve
        //public static string GenerateStoredKey(string key, Type t)
        //{
        //    return string.Format("{0}-{1}", t.FullName, key);
        //}
    }

Then to use it you have something like this

  //Now we load our saved refreshToken.
  StoredResponse myStoredResponse = new StoredResponse(tbRefreshToken.Text);
 // Now we pass a SavedDatastore with our StoredResponse.

    credential = GoogleWebAuthorizationBroker.AuthorizeAsync(
              new ClientSecrets { ClientId = "YourClientId", ClientSecret = "YourClientSecret" },
              new[] { DriveService.Scope.Drive,
                DriveService.Scope.DriveFile },
              "user",
              CancellationToken.None,
               new SavedDataStore(myStoredResponse)).Result; }

Sample Project

I have created a small sample project for this. Google .net Samples Drive

Conclusion

Accessing Google APIs using OAuth2 is a matter of Creating your application on Google Developer console, telling the user what access you need buy supplying the scope. The google .net client library comes with filedatastore by default. We can change where the authentication information is stored by creating or own version of idatastore. I have a sample project that shows you how to change fileDataStore for storing information in the database as well as storing the files in the current working directory. Google .net Samples Authentication
